Micro Heat Regenerative Adsorption Compressed Air Dryer

Application
Micro heat regenerative adsorption dryer is widely used in metallurgy, electric power, electron, food processing, chemical and oil field, etc. Such adsorption air dryer features heat regeneration and heatless regeneration. It takes micro heating method. Thus, it is characterized by low electric energy loss and low gas consumption. Besides, micro heat regenerative adsorption dryer has reasonable switching time.

Features
1. As for its structure, heating device is added to such adsorption air dryer. As for the regenerating process, returning and cold blowing process are added.
2. Micro heat regenerative adsorption dryer features low energy consumption (only6%).
3. It has reasonable switching period, thus, the parts and components are wear less, which improves the reliability of such adsorption air dryer.
4. Compared with the heatless type, micro heat regenerative adsorption dryer features better dryness.

Working Condition and Technical Indicator
Purge Air: ≤ 4% to 6%
Working Pressure: 0.4MPa to 1.0MPa
Inlet Oil Content: ≤ 0.01ppm
Outlet Air Pressure Dew Point: -20℃ to -70℃
Desiccant: Activated Aluminum Oxide or Molecular Sieve
Working Period: T= 60 min to 180min
Inlet Temperature: 0℃ to 45℃

Technological Process

A, B Absorber
3, 4, 6, 7Check Valve
5. Silencer
8. Throttle Valve
9. Programming Controller
10. Electrical Heater
A1, A2, B1, B2 Changeover Valve

Detailed Model Parameters of Micro Heat Regenerative Adsorption Dryer

Model	Air Processor (Nm³/min)	Heater Power (Kw)	Air Interface Size	Dimension (mm)			Weight (kg)
				Length	Width	Height
SAD-1MXF	1.2	1	ZG1	700	370	1062	180
SAD-2MXF	2.4	1	ZG1	700	370	1483	300
SAD-3MXF	3.8	2	ZG1.5	850	470	1655	350
SAD-6MXF	6.5	2	ZG2	1000	570	1965	510
SAD-10MF	10.7	3	ZG2	1250	620	2002	720
SAD-13MXF	13.5	3	DN65	1250	620	2120	780
SAD-20MXF	25	4	DN80	1250	745	2354	1280
SAD-30MXF	35	4	DN100	1300	745	2595	1760
SAD-40MXF	45	6	DN125	1400	915	2595	2200
SAD-50MXF	55	6	DN125	1840	1075	2595	2600
SAD-60MXF	65	8	DN125	1840	1075	2595	3100
SAD-80MXF	85	8	DN150	2300	1265	2595	4100
SAD-100MXF	110	10	DN150	2800	1265	3200	5200
SAD-160MXF	160	15	DN200	2800	1320	3200	6000

Bristol Compressors (Shanghai) Co., Ltd. is a professional supplier of micro heat regenerative adsorption dryer in China. We provide high quality adsorption air dryer with multi-features. We have strict quality checking system so as to guarantee the quality of our products. Bristol (Shanghai) Co., Ltd. never compromises to sacrifice quality to get low price. For detailed information about our micro heat regenerative adsorption dryer, please visit our website and contact us directly.
