HM460 Diesel Portable Screw Air Compressor
Main Features
1. Diesel portable screw air compressor adopts high efficient and energy-saving main unit with reliable durability and easy operation.
2. Such diesel air compressor is equipped with Cummins generator so as to provide durable drive with long life time and low economical oil consumption.
3. HM460, HM500 and HM600 diesel portable screw air compressor employs scientific sound absorption and vibration reductions technology to provide low-noise operation of the machine.
4. Such diesel air compressor has human-friendly automatic alarm and shutdown protection function.
5. Diesel portable screw air compressor makes use of reasonable fan and cooler design to ensure operation under low and high temperature.
6. Such diesel air compressor makes use of simple design concept, making it easy to operate and convenient to repair.
Technical Data
Model:HM460-14, HM500-10, HM600-7
| Model | HM460-14 | HM500-10 | HM600-7 | |
| Air Compressor | Air Discharge Volume (m3/min) | 11.3 | 12.8 | 17 |
| Working Pressure (bar) | 14 | 10 | 7 | |
| Lubricating Oil Volume (L) | 36 | 36 | 36 | |
| Compression Phase | 1 | 1 | 1 | |
| Joint Size | G3/4,G1 1/4,G2 | G3/4,G1 1/4,G2 | G3/4,G1 1/4,G2 | |
| Noise dB(A) | 76 | 76 | 76 | |
| Generator | Manufacturer | Cummins | Cummins | Cummins |
| Model | GBTA5.9 | GBTA5.9 | GBTA5.9 | |
| Cylinder No. | 6 | 6 | 6 | |
| Cylinder Diameter (mm) | 102 | 102 | 102 | |
| Stroke (mm) | 120 | 120 | 120 | |
| Rated Power (kW) | 132 | 132 | 132 | |
| Rated Rotating Speed (rpm) | 2200 | 2200 | 2200 | |
| Idling (rpm) | 1400 | 1400 | 1400 | |
| Lubricating Oil Volume (L) | 13 | 13 | 13 | |
| Fuel Tank Volume ( L) | 310 | 310 | 310 | |
| Storage Battery Voltage (V) | 24 | 24 | 24 | |
| Frame | L (mm) | 4579 | 4579 | 4579 |
| W (mm) | 2018 | 2018 | 2018 | |
| H (mm) | 2350 | 2350 | 2350 | |
| N.W (kg) | 2500 | 2500 | 2500 | |
Bristol Compressors (Shanghai) Co., Ltd. is a specialized supplier and exporter of diesel portable screw air compressor, diesel air compressor and Bristol compressor in China. We are engaged in manufacturing portable screw air compressor or mobile screw compressor, oil injected screw air compressor, micro oil screw type and oil free screw model, etc. For detailed information, please visit our website and contact us directly.
