Oil Free Piston Air Compressor

Main Features
1. 100% Pure Compressed Air.
2. Oil free piston air compressor adopts many latest patent technologies.
3. It’s an environmental friendly product with oil free lubrication and non environmental pollution.
4. Oil free piston compressor features easy operation, automatic start and shutdown.
5. Oil free piston air compressor is characterized by long lifetime and high reliability.
6. With imported bearings with high accuracy and imported materials, oil free piston compressor has the feature of low cost, low consumption, oil\electricity\human resource saving.
7. With new technique, oil free piston air compressor is economical and durable.
8. With nitride anticorrosion and compressed PTFE lubrication parts, such piston compressor is endowed with good lubrication and durability.

Mode of Transportation and Payment
By sea; T/T
Only ship the goods upon receiving the total payment.

Technical Data of Oil Free Piston Air Compressor

Specifications	Power		Cylinder Dia. × No.	Stroke	Rotating Speed	Airflow Volume	Rated Pressure	Max. Working Pressure	Air Tank Volume	Overall Dimensions L × W × H	Weight
Model	HP	kW	PCS × mm	mm	r/min	m3/min	MPa	Mpa	m3	mm	kg
WW-0.4/7	4	3	70 × 3	55	860	0.4	0.7	0.8	0.175	1470 × 470 × 980	215
WW-0.3/12.5	4	3	70 × 2  55 × 1	55	1050	0.3	1.25	1.40	0.175	1470 × 470 × 980	215
WW-0.5/7	5.5	4	70 × 3	55	850	0.5	0.7	0.8	0.175	1470 × 470 × 980	225
WW-0.45/12.5	5.5	4	70 × 2  55 × 1	55	1050	0.4	1.25	1.4	0.175	1470 × 470 × 980	225
WW-0.65/12.5	7.5	5.5	100 × 2   80 × 1	72	780	0.65	1.25	1.4	0.25	1800 × 700 × 1460	295
WW-1.0/7	10	7.5	100 × 3	72	860	1.0	0.7	0.8	0.312	1800 × 700 × 1460	335
WW-0.75/12.5	10	7.5	100 × 2   80 × 1	72	860	0.75	1.25	1.4	0.312	1800 × 700 × 1460	335
WW-1.5/7	15	11	125 × 2 110 × 1	80	800	1.5	0.7	0.8	0.312	1800 × 780 × 1500	480
WW-1.28/12.5	15	11	125 × 2 100 × 1	80	800	1.28	1.25	1.4	0.312	1800 × 780 × 1500	480
WW-2.0/7	20	15	125 × 2 110 × 1	110	800	2.0	0.7	0.8	0.50	1910 × 800 × 1650	620
WW-1.8/10	20	15	125 × 2 100 × 1	110	800	1.8	1.0	1.15	0.50	1910 × 800 × 1650	620
WW-1.6/12.5	20	15	125 × 2 100 × 1	110	800	1.6	1.25	1.4	0.50	1910 × 800 × 1650	620
WW-3.0/7	25	18.5	125 × 3	110	800	3.0	0.7	0.8	0.50	1910 × 800 × 1650	650

Bristol Compressors (Shanghai) Co., Ltd. is a professional maker of oil free piston air compressors (oil free piston compressors) in China. We are engaged in various air compressors, like oil injected screw air compressor, oil less screw type and oil free screw model and piston air compressor, etc. For more information about our products, please visit our website and contact us directly.
